30" (762) Chimney Wall Hood – Overall Dimensions
36" (914) Chimney Wall Hood – Overall Dimensions
Chimney Island Hood – Overall Dimensions
W OLF C OOKTOP V ENTILATION
PLANNING
INFORMATION
Chimney Wall Hoods –
Available in classic stainless steel,
30" (762) and 36" (914) wide by 21"
(533) deep.
Chimney Island Hood –
Available in classic stainless steel,
42" (1067) wide by 27" (686) deep.
IMPORTANT NOTE: Wolf chimney
wall and island hoods are recom-
mended for use with Wolf electric,
gas and integrated cooktops, and
should be as least as wide as the
cooking surface. A Pro Series ventila-
tion hood must be used with Wolf
dual fuel ranges, gas ranges and
rangetops, refer to pages 69-78.
Wolf chimney wall and island hoods
come with a telescopic chimney flue
extension that allows you to reach a
ceiling height of 8' (2.4 m) to 9'
(2.7 m) with a finished look. A flue
extension to accommodate 10' (3 m)
ceilings is available. Contact your
Wolf dealer for information on
optional accessories.
These illustrations of the three
chimney hoods give you overall
dimensions, while the installation
dimensions are provided in the illus-
trations on the following pages.
Dimensions in parentheses are in millimeters unless otherwise specified.
