64
W OLF C OOKTOP V ENTILATION
Dimensions in parentheses are in millimeters unless otherwise specified.
ROOF CAP OR REMOTE BLOWER
8" (203) ROUND DUCT
8" (203) ROUND ELBOW
CHIMNEY FLUE EXTENSION
TELESCOPIC CHIMNEY FLUE
8" (203) ROUND DUCT
24" TO 30"
(610 - 762)
COOKING SURFACE
TO BOTTOM OF
VENTILATION HOOD
CHIMNEY
ISLAND HOOD
DUCTWORK INSTALLATION
THROUGH ROOF
DUCTWORK
INSTALLATION
THROUGH EAVE
8" (203) ROUND
ELBOW
EAVE VENT
9
1
/4" (235)
27"
(686)
8" (203) ROUND
VERTICAL
DISCHARGE
PLANNING
INFORMATION
The Wolf chimney island hood has an
8" (203) round vertical discharge.
Ducting for the chimney island hood
can run through the roof or through
an eave as shown in the illustration.
Refer to the cooktop ventilation
charts on pages 79-80 for recommen-
dations and blower options.
Ducting considerations for chimney island hood.
