W OLF C OOKTOP V ENTILATION
DOWNDRAFT
VENTILATION SYSTEMS
The cooktop downdraft unit rises
from the countertop to whisk away
odors and smoke into the easy-to-
clean, five-layer mesh filter. The
control module and top cover are
available in the exclusive premium
finishes of platinum or carbon stain-
less steel, or the standard classic
stainless steel for ease in matching
your cooktop.
IMPORTANT NOTE: Wolf downdraft
ventilation systems are recommended
for use with Wolf framed electric and
gas cooktops and integrated
modules. They cannot be installed
with unframed electric cooktops or
the electric steamer or fryer modules.
A Pro Series ventilation hood must be
used with Wolf dual fuel ranges, gas
ranges and rangetops, refer to pages
69-78.
Wolf Downdraft systems come in 30"
(762) and 36" (914) widths. The
control module and top cover are
available in the classic, platinum and
carbon stainless steel finishes.
These illustrations of the two
downdraft sizes, give you overall
dimensions, while the installation
dimensions are provided in the illus-
trations on the following pages.
2
3
/8"
(60)
30"
(762)
9
1
/16"
(230)
26
1
/4"
(667)
1
1
/2" (38)
DEPTH OF
DOWNDRAFT CHIMNEY
36"
(914)
32
1
/4"
(819)
2
3
/8"
(60)
9
1
/16"
(230)
1
1
/2" (38)
DEPTH OF
DOWNDRAFT CHIMNEY
30" (762) Downdraft
Overall Dimensions
36" (914) Downdraft
Overall Dimensions
FEATURES
• Classic, platinum or carbon
stainless steel finishes available on
control module and top cover
• Remote mounted control module
• Internal and remote blower
options
• Three-speed blower control
• Filter clean timer lets you know
when the filter needs cleaning
• Delay off feature automatically
turns unit off, chimney remains up
• Stainless steel filter cover with
dishwasher safe aluminum mesh
filter
• LED indicators
• 9" (229) chimney elevation
• Downdraft control kit includes
control module, top cover,
mounting brackets, DIN connector
and necessary hardware
• UL listed to US and Canadian
safety standards
• Two and five year residential
warranty – exclusions apply, see
warranty at the end of this guide
MODEL / BLOWER
OPTIONS
30" (762) Downdraft
500 cfm Internal Blower
(included) DD30I
Downdraft Only
(requires remote blower) DD30R
36" (914) Downdraft
500 cfm Internal Blower
(included) DD36I
Downdraft Only
(requires remote blower) DD36R
Model DD30
Model DD36
TRIM OPTIONS
Model DD30
30" (762) Control Kit w/Top Cover
Classic Stainless DD30CONTROL/S
Platinum Stainless DD30CONTROL/P
Carbon Stainless DD30CONTROL/B
Model DD36
36" (914) Control Kit w/Top Cover
Classic Stainless DD36CONTROL/S
Platinum Stainless DD36CONTROL/P
Carbon Stainless DD36CONTROL/B
Downdraft control kits are ordered
and shipped as sales accessories.
