C OOKTOP V ENTILATION R ECOMMENDATIONS
BLOWER OPTIONS
Chimney Wall Hoods Blower Number Transition Duct Size
CTWH30 Internal 450 CFM CTBLOWER-45INT (801643) Not Required 8" (203) Round
CTWH36 Internal 600 CFM CTBLOWER-60INT (801644) Not Required 8" (203) Round
CTWH36 Internal 900 CFM CTBLOWER-90INT (801645) Not Required 8" (203) Round
CTWH30 / CTWH36 Remote 600 CFM CTBLOWER-60REM (801640) TRANS-8-10 8" (203) Round
CTWH30 / CTWH36 Remote 900 CFM CTBLOWER-90REM (801641) TRANS-8-10 8" (203) Round
CTWH30 / CTWH36 Remote 1200 CFM CTBLOWER-120REM (801642) TRANS-8-10 8" (203) Round
CTWH30 / CTWH36 Remote 1500 CFM CTBLOWER-150REM (804701) TRANS-8-10 8" (203) Round
NOTE: Backdraft included.
Vertical or horizontal discharge. Horizontal discharge is only applicable on 22" (559) wall hoods (excluding W302210I and W362210I) and
24" (610) wall hoods used with a WBLOWER-120INT (804702) or any Wolf remote blower. WBLOWER-90INT (805086) is not for use in
rear discharge applications.
Chimney Island Hoods Blower Number Transition Duct Size
IH4227 Internal 600 CFM CTBLOWER-60INT (801644) Not Required 8" (203) Round
IH4227 Internal 900 CFM CTBLOWER-90INT (801645) Not Required 8" (203) Round
IH4227 Remote 600 CFM CTBLOWER-60REM (801640) TRANS-8-10 8" (203) Round
IH4227 Remote 900 CFM CTBLOWER-90REM (801641) TRANS-8-10 8" (203) Round
IH4227 Remote 1200 CFM CTBLOWER-120REM (801642) TRANS-8-10 8" (203) Round
IH4227 Remote 1500 CFM CTBLOWER-150REM (804701) TRANS-8-10 8" (203) Round
NOTE: Backdraft included. Vertical discharge.
Downdrafts Blower Number Transition Duct Size
DD30I / DD36I Internal 500 CFM Included Not Required 3
1
/
4
" (83) x 10" (254)
DD30R / DD36R Remote 900 CFM CTBLOWER-90REM (801641) TRANS-14-10 3
1
/
4
" (83) x 14" (356)
DD30R / DD36R Remote 1200 CFM CTBLOWER-120REM (801642) TRANS-14-10 3
1
/
4
" (83) x 14" (356)
DD30R / DD36R Remote 1500 CFM CTBLOWER-150REM (804701) TRANS-14-10 3
1
/
4
" (83) x 14" (356)
NOTE: Adjustable discharge.
Blower configurations are for reference only. Please refer to minimum CFM recommendations for your specific cooking product. Always
consult a qualified HVAC Engineer for specific applications.
Dimensions in parentheses are in millimeters unless otherwise specified.
