Rev AB Other Components 3-11
Wolke m600 Universal Operator Manual
USB Connector
The printer also has a USB connector, which is used for data transmission
to the printer using USB Stick.
Mounting System
Mounting System shows the typical mounting of controller (see
Figure 3-16) and printhead (see Figure 3-17 on page 3-12) onto a
production line.
Figure 3-16: Controller Mounting System
Option 1
Option 2
