Rev AB Using the Tools Page 4-9
Wolke m600 Universal Operator Manual
System Configuration Allows the user to configure the printer for
installation. For more information refer “Setting up
the Printer” on page 5-9.
Recalibrate Touchscreen Allows the user to recalibrate the touchscreen, if
touching the screen does not accurately locate the
correct CLARiTY button or Icon. The printer
requests the user to touch several crosses which
are displayed on the screen, one after the other.
The screen is recalibrated when the automated
process is complete.
Note: If the calibration of the machine has too
many errors and does not allow a user to navigate
to this screen via the CLARiTY panel, the same
functionality can be triggered from within
CLARiTY Configuration manager (for more
information, refer to Service Manual (P/N:
WLK462431).
Set Screen Orientation Allows the user to rotate the entire display through
180 degrees in the event that the CLARiTY panel
is installed in an inverted orientation
Date and Time Allows the user to set the system date and time of
the printer.
Image Control Allows the fine adjustment of the barcode.
Note: Do not adjust the Barcode Fine Adjust
value from it's default setting without first printing
the "Barcode Control Image" test pattern to
determine the proper value. Improperly adjusting
this value could cause barcodes and 2D codes to
become unreadable.
Communications Allows the user to reset the printer's serial port to
factory default settings. These default settings
configure the printer to communicate with
CLARiSOFT
®
and CLARiTY Configuration
Manager.
Buttons Description
Table 4-4: Control Page (Continued)
