MEASURING AC & DC CURRENT
How to measure : First, turn off the power of the circuit, and, discharge
the high voltage capacitor. Fix the red lead into the terminals of mA and
10A in accordance with the value to be measured. Select one of the buttons
& . When & are selected, place the red lead on
mA, and When button is selected, place the red lead on 10A.
4. Functional Use
27
Current is simply defined as a flow of electrons running through a
conductor. To measure current, you must break the circuit under test, and
then place the meter in series with the circuit. The current measuring range
of the meter is 10A max.
