ඝ UTP CABLE TESTER
㯲
Connect UTP cable to be tested to UTP port of RAPPORT337, while
connect the other end to UTP tester.
The connected condition of the cable can be checked, by pressing
key, after the connection is completed. Direct cable and cross cable can be
classified, and disconnection or short-circuit can be also examined.
Cross cable Short-circuit & Disconnection
DIRECT
Direct cable
