45
1 WMBH-2-1 Base assembly weldment 1
2 WMBH-2-2 Valve mounting plate 1
3 WMBH-2-3 Boom swivel weldment 1
4 WMBH-2-4 Seat support plate weldment 1
5 WMBH-2-5 Seat mounting plate 1
6 (See Diagram 6-19) Hydraulic oil tank
7 (See Diagram 6-14) Oil lter
8 (See Diagram 6-6) Oil gauge
9 (See Diagram 6-50) Swing cylinder
10 (See Diagram 6-64) 8-way valve
11 (See Diagram 6-63) 6-way valve
12 WMBH-2-12 Front console cover 1
13 WMBH-2-13 Upper console cover 1
14 WMBH-2-14 Console grab bar 1
15 WMBH-2-15 Seat 1
16 WMBH-2-16 Swing cylinder pin (20x110mm (4-3/8”) 4
17 WMBH-2-17 Suspension pin weldment 2
18 WMBH-2-18 Swivel weldment lock pin (20x90mm (3-1/2”) 1
19 WMBH-2-19 Buffer block 2
20 Blank
21 M20 FW M20 Flat washer zinc 16
22 M8x1.25x70 HHCS M8x1.25x70 Hex head cap screw GR8.8 zinc 3
23 M8x1.25x55 HHCS M8x1.25x55 Hex head cap screw GR8.8 zinc 2
24 M8x1.25x65 HHCS M8x1.25x65 Hex head cap screw GR8.8 zinc 2
25 M8x1.25x45 HHCS M8x1.25x45 Hex head cap screw GR8.8 zinc 4
26 M8x1.25 NYLOCK M8x1.25 Nylon lock nut 6
27 M10x1.5x25 KNOB Seat retaining bolt w/knob (M10x1.5x25) 1
28 M10 FEN. W M10x25 Fender washer zinc 5
29 WMBH-2-29 Seat connector pin (1/2”x6-1/4”) 1
30 M12 FEN. W M12x25 Fender washer zinc 17
31 CP-2.5x35 Cotter pin 2.5x35mm 1
32 WMBH-2-32 Spacer (45mmID x 75mmOD x 4.75mm thick) 2
33 CP-3.5x50 Cotter pin 3.5x58mm 16
34 M8 FW M8 Flat washer zinc 21
35 M8 SLW M8 Med split lock washer zinc
36 M8x1.25x20 HHCS M8x1.25x20 Hex head cap screw GR8.8 zinc 14
37 M10 SLW M10 Med split lock washer zinc 4
38 M8x1.25x35 SHCS M8x1.25x35 Socket hea dcap screw 4
39 M8x1.25x80 HHCS M8x1.25x80 Hex head cap screw GR8.8 zinc 2
PARTS & DIAGRAMSPARTS & DIAGRAMS
WM-6600/7600/8600 – Sub Frame/Stabilizer Assembly – Diagram 2 – Parts List
Pos No. Part No. Description Qty
