46
40 M8x1.25x30 SHCS M8x1.25x30 Socket head cap screw 1
41 M6 FW M6 Flat washer zinc 6
42 M6x1.0 NYLOCK M6x1.0 Nylon lock nut 3
43 M6x1.0x20 HHCS M6x1.0x20 Hex head cap screw GR8.8 zinc 3
44 M12x1.75 NYLOCK M12-1.75 Nylon lock nut 12
45 M12x1.75x45 HHCS M12x1.75x45 Hex head cap screw GR 8.8 zinc 4
46 RP-3.5x75 R-shaped cotter pin (3.5x75mm OAL) 1
47 M8 FEN. W M8x24 Fender washer 4
48 M8-1 SGF M8x1.0 Strait grease tting 2
49 (See Diagram 6-62) Italian main control valve (Hydro)
50 M16 FW M16 Flat washer zinc 1
51 DP-M16x1.5 Drain plug M16×1.5 1
52 (See Diagram 6-16) Oil tank cap
53 WMBH-2-53 Stabilizer leg 2
54 WMBH-2-54 Stand foot 2
55 (See Diagram 6-48) Stabilizer leg cylinder
56 WMBH-2-56 Stabilizer leg cylinder pin (20x140mm (5-1/2”) 4
57 WMBH-2-57 Stabilizer leg cylinder x pin 2
58 WMBH-2-58 Stabilizer leg x pin (20x95mm (3-3/4”) 2
59 WMBH-2-59 Rubber foot pad 4
WM-6600/7600/8600 – Sub Frame/Stabilizer Assembly – Diagram 2 – Parts List (continued)
Pos No. Part No. Description Qty
