PARTS & DIAGRAMSPARTS & DIAGRAMS
WM-6600/7600/8600 – Hydraulic Components – Diagram 6 – Parts List
1 WMBH-6-1 Pump support bracket 1
2 WMBH-6-2 Torque prevention chain 1
WMBH-6-3-6-7 PTO pump (WM6600, WM7600) 1
WMBH-6-2-8 PTO pump (WM8600) 1
4 6801-12-16 90° angle tting (6801-12 JIC-16 Male boss) 1
5 WMBH-6-5 Suction hose (-12 JIC -12 JIC, 45” AOL) 1
6 WMBH-6-6 Oil gauge 1
7 WMBH-6-7 Oil lter screen (suction screen) 1
8 M8x1.25x16 HHCS M8x1.25x16 Hex head cap screw GR8.8 zinc 6
9 WMBH-6-9 Tank ange tting gasket 1
10 M8 SLW M8 Med split lock washer zinc 24
11 EYE BOLT M8x50 Eye bolt (M8x50) 1
12 6801-8-12 90° angle tting (6801-8 JIC-12 Male boss) 1
13 WMBH-6-13 Oil lter tting (M22x1.5 to UNF 3/4-16) 1
14 WMBH-6-14 Oil lter RFA-25×10L 1
15 M8x1.25x55 HHCS M8x1.25x55 Hex head cap screw GR8.8 zinc 6
16 WMBH-6-16 Oil tank ller cap assembly 1
17 9500-10 Bonded seal (7/8” ID- 1-1/4” OD) 1
18 WMBH-6-18 Outlet hose 6B.6B (-8 JIC, -.75 BF 47.5” OAL) 1
19 WMBH-6-19 Hydraulic oil tank 1
20 9500-08 Bonded seal (3/4” ID- 1-1/16” OD) 34
21 6410-12-12 3/4-16 ORB 1-1/8” Long extension 6
22 WMBH-6-22 Hose (right swing cylinder) 6P.6P (-5 JIC-.75 BF, 42” OAL) 1
23 BNJB.75x16x1.25 3/4-16x1-1/4” Hollow banjo bolt zinc 14
24 WMBH-6-24 Main pressure hose 6A.6A (-8 JIC-.75 BF, 68” OAL) 1
25 WMBH-6-25 Hose (left swing cylinder) 6G.6G (-5 JIC-.75 BF, 41” OAL) 1
26 WMBH-6-26 Hose (main valve to 8-way valve) 6Q8T 1
27 WMBH-6-27 Hose (main valve to 6-way valve) 6M21 1
WMBH-6-28-6 Bucket cylinder hose (WM-6600) 6C.6C (-5 JIC-.75 BF, 106.5” OAL) 1
WMBH-6-28-7 Bucket cylinder hose (WM-7600) 6C.6C (-5 JIC-.75 BF, 117” OAL) 1
WMBH-6-28-8 Bucket cylinder hose (WM-8600) 6C.6C (-5 JIC-.75 BF, 129” OAL) 1
29 WMBH-6-29 Hose in (left leg cylinder) 6N.6N (-5 JIC-.75 BF, 47” OAL) 1
30 WMBH-6-30 Hydraulic tube (steel) 6K8Y 1
31 WMBH-6-31 Hydraulic tube (steel) 6H8V 1
32 WMBH-6-32 Hose out (left leg cylinder) 6F.6F (-5 JIC-.75 BF, 42” OAL) 1
33 WMBH-6-33 Hydraulic tube (steel) 6E22 1
WMBH-6-34-6 Boom cylinder (WM-6600) 1
WMBH-6-34-7 Boom cylinder (WM-7600) 1
WMBH-6-34-8 Boom cylinder (
WM-8600) 1
WMBH-6-35-6 Bucket cylinder hose (WM-6600) 6J.6J (-5 JIC-.75 BF, 106.5” OAL) 1
WMBH-6-35-7 Bucket cylinder hose (WM-7600) 6J.6J (-5 JIC-.75 BF, 117” OAL) 1
WMBH-6-35-8 Bucket cylinder hose (WM-8600) 6J.6J (-5 JIC-.75 BF, 129” OAL) 1
36 WMBH-6-36 Hydraulic tube (steel) 6D8Z 1
WMBH-6-37-6 Dipper cylinder (WM-6600) 1
WMBH-6-37-7 Dipper cylinder (WM-7600) 1
WMBH-6-37-8 Dipper cylinder (WM-8600) 1
WMBH-6-38-6 Hose in (thumb cylinder) (WM-6600) 25.25 (-5 JIC, -2” 90 deg .5 BF, 122.5”) 1
WMBH-6-38-7 Hose in (thumb cylinder) (WM-7600) 25.25 (-5 JIC, -2” 90 deg .5 BF, 126”) 1
WMBH-6-38-8 Hose in (thumb cylinder) (WM-8600) 25.25 (-5 JIC, -2” 90 deg .5 BF, 138”) 1
Pos No. Part No. Description Qty
3
28
34
35
37
38
