www.WoodMaxx.com
52
WMBH-6-39-6 Hose out (thumb cylinder) (WM-6600) 26.26 (-5 JIC, -2” 90 deg .5 BF, 122.5”) 1
WMBH-6-39-7 Hose out (thumb cylinder) (WM-7600) 26.26 (-5 JIC, -2” 90 deg .5 BF, 126”) 1
WMBH-6-39-8 Hose out (thumb cylinder) (WM-8600) 26.26 (-5 JIC, -2” 90 deg .5 BF, 138”) 1
WMBH-6-40-6 Bucket cylinder (WM-6600) 1
WMBH-6-40-7 Bucket cylinder (WM-7600) 1
WMBH-6-40-8 Bucket cylinder (WM-8600) 1
WMBH-6-41-6 Hose in (dipper cylinder) (WM-6600) 8R.8R (-5 JIC-.5 BF, 78” OAL) 1
WMBH-6-41-7 Hose in (dipper cylinder) (WM-7600) 8R.8R (-5 JIC-.5 BF, 85” OAL) 1
WMBH-6-41-8 Hose in (dipper cylinder) (WM-6600) 8R.8R (-5 JIC-.5 BF, 94” OAL) 1
WMBH-6-42-6 Hose out (dipper cylinder) (WM-6600) 8S.8S (-5 JIC-.5 BF, 78” OAL) 1
WMBH-6-42-7 Hose out (dipper cylinder) (WM-7600) 8S.8S (-5 JIC-.5 BF, 85” OAL) 1
WMBH-6-42-8 Hose out (dipper cylinder) (WM-8600) 8S.8S (-5 JIC-.5 BF, 94” OAL) 1
43 WMBH-6-43 Hose out (right leg cylinder) 24.24 (-5 JIC-.5 BF, 41.5” OAL) 1
44 WMBH-6-44 Hose in (right leg cylinder) 23.23 (-5 JIC-.5 BF, 41.5” OAL) 1
45 WMBH-6-45 Tank hose tting suction ange (-12 JIC) 1
WMBH-6-46-6 Hose in (boom cylinder) (WM-6600) 8X.8X (-5 JIC-.5 BF, 72.5” OAL) 1
WMBH-6-46-7 Hose in (boom cylinder) (WM-7600) 8X.8X (-5 JIC-.5 BF, 79.5” OAL) 1
WMBH-6-46-8 Hose in (boom cylinder) (WM-8600) 8X.8X (-5 JIC-.5 BF, 87.5” OAL) 1
WMBH-6-47-6 Hose out (boom cylinder) (WM-6600) 8W.8W (-5 JIC-.5 BF, 72.5” OAL) 1
WMBH-6-47-7 Hose out (boom cylinder) (WM-7600) 8W.8W (-5 JIC-.5 BF, 79.5” OAL) 1
WMBH-6-47-8 Hose out (boom cylinder) (WM-8600) 8W.8W (-5 JIC-.5 BF, 87.5” OAL) 1
48 WMBH-6-48 Stabilizer cylinder (All) 2
49 WMBH-6-49 Thumb cylinder (All) 1
50 WMBH-6-50 Swing cylinder (All) 2
51 M8 FW M8 Flat washer zinc 12
52 WMBH-6-52 Reversing oil hose for swing cylinder HH 2
53 6804-04-04-04 3- way tting (6804-04-04-04) 2
54 6410S-05-05 1/2-20 UNF tting extension (9/16” long) 4
55 9500-04 Bonded seal (1/2” ID- 13/16” OD) 37
56 WMBH-6-56 Support base plate for valve 1
57 BNJB.50x20x1.125 1/2-20x1-1/8” Hollow banjo bolt zinc 16
58 M8x1.25x20 HHCS M8x1.25x20 Hex head cap screw GR8.8 zinc 1
59 6410L-05-05 1/2-20 UNF tting extension (1” long) 1
60 4001-12 Viton O-Ring for #12 SAE/ORB 1
61 4001-16 Viton O-Ring for #16 SAE/ORB 1
62 WMBH-6-62 Italian main control valve(Hydro) 1
63 WMBH-6-63 6-way valve 4
64 WMBH-6-64 8-way valve 1
65 M8x1.25x60 HHCS M8x1.25x60 Hex head cap screw GR8.8 zinc 3
66 M8x1.25x80 HHCS M8x1.25x80 Hex head cap screw GR8.8 zinc 2
67 M8x1.25x25 HHCS M8x1.25x25 Hex head cap screw GR8.8 zinc 1
68 M8x1.25 NUT M8x1.25 Hex nut zinc 2
69 M12 SLW M12 Med split washer zinc 2
70 M12 FW M12x25mm Flat washer zinc 2
71 M12x1.75x25 HHCS M12x1.75x25 Hex head cap screw GR 8.8 zinc 2
72 WMBH-6-72 D-ring 1
WM-6600/7600/8600 Hydraulic Components – Diagram 6 – Parts List (continued)
PARTS & DIAGRAMSPARTS & DIAGRAMS
Pos No. Part No. Description Qty
39
40
41
42
46
47
