www.WoodMaxx.com
53
Hydraulic Conversion Kit – Diagram 7 (To run backhoe using tractor hydraulics)
2
5
7
5
3
10
8
8
4
9
1
11
13
14
13
11
12
15
12
13
6
序号 存货编码 代号 名称 数量 材料 单重 总重
备注
1 11000201722
BH7-023
底座总成焊合件
1
110.54 110.54
2 14010100025
GB/T 5782-2000
六角头螺栓M8×55
2
5.6级
0
M8×55
3 14050100002
GB/T 889.1-2000
防松螺母M8
2
钢
0.005
0.01
4 14020000007
GB/T 93-1987
弹垫10
2
65Mn
0.002 0.004
10×2.6
5 14040000002
GB/T 95-2002
平垫圈8×1.6
4
钢
0.002 0.008
8×1.6
6
RFP3 V1110
流量调节阀
1
Q235/t5
0
7
12000005699
BH7600-153
固定板
1
Q235/t4
0.4 0.4
8 14040000003
GB/T 95-2002
平垫圈 10×2
4
钢
0.003 0.012
10×2
9 14010100039
GB/T 5783-2000
六角头螺栓M10*25
2
8.8级
0.026 0.052
M10×25
10 14050100003
GB/T 889.1-2000
防松螺母M10
2
钢
0.009 0.018
11 11010700172
WM7600-135G
左转向油缸进油管 6G-6G
2
0.79 1.58
12 11010700171
WM7600-135X
大动臂油缸进油管8X-8X
2
0.39 0.78
13
11010600119
M18x1.5转G3/8
过渡接头
3
Q235/t5
0.0
0
14
代号 名称
1
Q235
0.125 0.125
15
I05821
整体六联阀
1
Q235
0.000
0
Type:
Specification:
Version:
Page :
PARTS & DIAGRAMSPARTS & DIAGRAMS
1 (see Diagram 3-1) Base frame weldment 1
2 M8x1.25x55 HHCS M8x1.25x55 Hex head cap screw GR8.8 zinc 2
3 M8x1.25 NYLOCK M8x1.25 Nylon lock nut 2
4 M10 SLW M10 Med split lock washer zinc 2
5 M8 FW M8 Flat washer zinc 4
6 WMBH-7-6 Flow control valve 1
7 WMBH-7-7 Mounting plate 1
8 M10 FW M10 Flat washer zinc 4
9 M10x1.5x25 HHCS M10x1.5x25 Hex head cap screw GR 8.8 2
10 M10x1.5 NYLOCK M10-1.5 Nylon lock nut 2
11 WMBH-7-11 Hydraulic hose 3/4-16 BF to 3/8-19BSPP Female (44” OAL) 2
12 WMBH-7-12 Hydraulic hose 1/2-14 NPT to3/8-19 BSPP Female (80” OAL) 2
13 307203 3/8-19 BSPP Male Stud adapter w/seal 3
14 9087-06-06-06 Branch Tee adapter with swivel nut 1
15 (see Diagram 6-62) Italian main control valve 1
Pos No. Part No. Description Qty
