Woods MDK21 User Manual

GB
6
Operating Instructions
PROBLEM CAUSE SOLUTION
Dehumidifier does not work The power is not connected - Check that dehumidifier is connected to electricity and that fuse has not gone
- Check that the water reservoir is empty and correctly placed in the dehumidifier.
Does not dehumidify -The water container is full.
-The water container has not
been replaced correctly.
-The air filter is clogged.
The temperature or relative
humidity in the room where
the device is operatingis too low.
- Remove the water from the container.
- Place the water container in the correct position.
- Clean the air filter.
- Check that air can flow freely through the dehumidifier. Front grid and air filter should be clean and dehumidifier should stand
20-30cm from wall
- Check that a thick coating of ice has not formed on the cooling coils.
The dehumidifier works, but
reduces the relative huidity
insufficiently.
-The room is too large.
-There are too many sources
of humidity.
-There is too much ventilation.
- We recommend using a dehumidifier with a greater capacity.
- We recommende using a dehumidifier with a greater capacity.
- Reduce ventilation (e.g close windows and shut doors.)
If none of the above works, you should contact your nearest retailer for checking and possible overhaul of dehumidifier
MDK21 MDK26
Max. working area 70m
2
120m
2
Air flow step 1 132m3/h 134m
3
/h
Air flow step 2 170m3/h 174m
3
/hour
Dehumidifying at 30˚C and 80% r.h. 20 l/24h 25l/24h
Power at 30˚C and 80% r.h. 240 W 260 W
Tank volume 4 liters 4 litres
Refrigerant R290 (70g) R290 (75g)
Voltage 230 V 230 V
Frequency 50 Hz 50 Hz
Currentt 1,15 A 1,2 A
IP Code IPX1 IPX1
Dimensions in mm, L x B x Hs 346x253x596 346x253x596
TECHNICAL DATA
*Technical changes and improvements may occur. All values are approximate and may vary due to external circumstances such as
temperature, ventilation and humidity.
