Parts 71
MAN0577 (6/29/2007)
CASTER ARM ASSEMBLY
REF PART QTY DESCRIPTION
1 39238 1 Caster yoke assembly
2 4984 1 Heavy hub with long axle
3 7428 1 6.00 x 9 Solid tire & rim 21 OD
4 39072 1 Center arm
5 39074 1 Damper arm
6 29070 1 Rubber pad
7 19459 1 Friction disc 4 x 6.15
8 12889 1 3/32 x 1-9/16 O-ring
9 12881 1 Tailwheel cap washer
10 4674 1 3/8 x 2 Spirol pin
11 11011 2 1-1/2 x 1-5/8 x 1-1/2 Bronze bushing
12 530 1 Heavy wheel hub with cap
13 6271 1 Long axle assembly for heavy hub
14 314 1 Seal for 1-1/2 shaft
15 310 2 Bearing cone
16 309 2 Bearing cup
17 531 1 Hub cap
18 1257 * 3/4 Standard flat washer
19 5849 3/4 NF Slotted Hex nut
20 1256 * 3/16 x 1 Cotter pin
REF PART QTY DESCRIPTION
21 3689 * 1" Standard lock washer
22 3626 * 1-14 UNS Hex nut
23 7431 1 Wheel, rim & hardware
24 7430 2 Rim half for 6.00 x 9 tire
25 N/S 1 6.00 x 9 Tire
26 838 * 3/8 Standard lock washer
27 835 * 3/8 NC Hex nut
28 19887 * 3/8 NC x 1 HHCS GR8
29 855 * 1/2 Heavy lock washer
30 4119 * 1/2 NF x 1 HHCS GR5
31 765 * 1/2 NC Lock washer
32 12305 * 1/2 NC x 5-1/2 HHCS GR5
33 378 * 5/8 NC x 5 HHCS GR5
34 6239 * 5/8 NC Hex lock nut
35 34279 1" NC Hex lock nut
36 15278 1" NC x 7-1/2 HHCS GR5
37 14350 * 3/8 NC Flange lock nut
38 839 * 3/8 NC x 1 HHCS GR5
39 12296 * 1/4 - 28 Grease fitting
40 1972 * 1/4 - 28 Tapered thread grease fitting
HHCS Hex Head Cap Screw
* Standard hardware, obtain locally
To Next Page
