49
ATTENTION
The brake lever must not touch the handlebar grip, even when applying maximum
strength. Only unscrew the adjusting screw counter clockwise so that the brake lever
does not touch the handlebar grip, even when the brake is applied with maximum
strength. Never unscrew the adjusting screw completely from the handlebar grip.
Shifter spacing
The default shifter position is set according to the woom UP model.
To change the shifter position, loosen the shifter clamping screw with a 5 mm hex key and
position the shifter according to your child's requirements. After positioning the shifter,
tighten the clamping screw to the tightening torque specied in Section 11.1 on page 60.
Make sure that your child can reach the shifter easily and eortlessly with his or her thumb.
Handlebar tilt
See also „Mounting the handlebar“ on page 43.
Loosen the screws of the stem
clamps a little.
Adjust the tilt of the handlebar. Tighten the screws alternately
until all are rmly tightened
again.
ATTENTION
Make sure that the handlebar is in the middle! The marking on the front helps to
ensure this.
Make sure that the clamps do not tilt and are evenly seated.
Make sure that the handlebar cannot be turned when the screws are tightened.
4 mm 4 mm
