6�4 Suspension fork
The woom UP comes with preset air pressure. If you want to adjust the air pressure, please
proceed as follows: To adjust the correct air pressure in the air suspension fork you need a
special absorber pump. First remove the valve cap (see gure) from the upper left end of the
air suspension fork by turning it counter clockwise. Fill the suspension fork with the correct
air pressure according to your child's body weight (see table). Screw the valve cap back onto
the valve.
Body weight (kg) Air pressure (psi)*
20-30 40-50
30-45 50-65
45-65 65-85
>65 85-100
*max. permissible air pressure: 150 psi
Adjusting rebound damping
Rebound damping and the rebound speed of the air suspension
fork can be adjusted with the red knob at the lower right end of
the fork. To increase the rebound speed and reduce rebound
damping, turn the red knob in the + direction. To reduce the
rebound speed and increase rebound damping, turn the knob
in the - direction. In order to adjust the rebound damping to the
needs of your child, please read the information on damping
adjustment in this section.
