11�2 Specications
Frame
• Frame material: lightweight, high-quality 6061 T6 aluminium with butted and hyd-
roformed tubes
• 24” / 26” wheel size
• Sporty handling: an easy-access low top tube, low centre of gravity and long wheelbase
provide good balance and make for a fun, safe riding experience.
Fork
• Suspension fork, adjustable damping and rebound damping, with lockout function,
80 / 90 mm suspension travel
• 1 1/8˝ - 1˝ baby taper shaft
• 100 x 15 mm quick release through axle
• Post mount for disc brake
Headset
• Fully integrated 1 1/8˝ - 1˝ headset
• Sealed industrial bearings
Stem
• Forged aluminium
• CNC-machined
• Handlebars attached with two clamps and secured with four 4 mm internal hex screws
• +/-15° ip-op design to adjust handlebar height
• Length: 50 mm
Handlebars
• Wide, ergonomically adapted and lightweight aluminium handlebars for more control
• Sandblasted and silver anodised
• Width: 600 / 680 mm
• Rise: 20 mm
Grips
• Child-friendly thanks to small diameter
• 100% silicon for maximum grip
• Non-toxic
• Handlebar ends with screwed-in end plugs
Drive
• Lightweight, forged 130 / 150 mm aluminium cranks with narrow tread (Q-factor)
• Narrow-wide chainring with 28 teeth in the front
• 11-sprocket cassette with 11-42 teeth in the back
• Flat pedals made from bre-reinforced nylon
• Cr-Mo axle and sealed industrial ball bearings
Brake
• Hydraulic disc brakes from Promax
• Rear/front disc diameter: 160 / 140 mm
• Ergonomic brake levers designed for children's hands
Gears
• 11 speeds
• SRAM NX Trigger shifter
• SRAM NX rear derailleur
Wheels
• Superlight woom UP DISCO TEC double-chamber aluminium rims
• Aluminium hubs with sealed industrial bearings
• Through axles for maximum torsional strength (135 x 12 mm rear)
• with 24˝: 20 G14 spokes, double-crossed spoking
• with 26˝: 28 G14 spokes, triple-crossed spoking
• Brass nipples
