Worcester 35CDi II User Manual

27
17. Short Parts List
Part WHS Part No.
Horizontal Telescopic Flue Kit 7 716 191 068
Flue Duct Extension Kit 7 716 191 006
Vertical Balanced Flue Kit & Terminal 7 716 191 079
Vertical Flue Adaptor 7 716 191 016
Digital Single Channel Programmer 7 716 192 003
Mechanical Single Channel Programmer 7 716 192 002
Digistat CD (Radio Controlled Room Thermostat) 7 716 192 006
Wall Spacing Frame 24/28CDi 7 716 192 111
90° Flue Elbow (One) 7 716 191 013
45° Flue Elbow (Pack of Two) 7 716 191 014
Mini Expansion Vessel 7 716 192 105
Internal Flue Fixing Kit 7 716 191 018
Wall Spacing Frame 35CDi II 7 716 192 278
Pre-System Filling Kit
7 716 192 102
Accessories
26 E80-450 Gas Valve – Natural Gas Dungs BM 771 SL 040 1 8 716 102 673 0
26 Gas Valve – Propane Dungs BM 771 SL 040 1 8 716 102 868 0
78 E00-720 Burner – Natural Gas Aeromatic, Ref. AC 23/05 3584 1 8 716 142 603 0
78 E00-737 Burner – Propane Aeromatic, Ref. AC 23/05 3585 1 8 716 142 605 0
78 375 695 Burner – Natural Gas Aeromatic, Ref. AC 23/05 3582 1 8 716 142 602 0
78 173 012 Burner – Propane Aeromatic, Ref. AC 23/05 3583 1 8 716 142 600 0
78 Burner – Natural Gas Aeromatic, Ref. AC 23/05 3598 1 8 716 102 674 0
78 Burner – Propane Aeromatic, Ref. AC 23/05 3599 1 8 716 102 869 0
80 E00-721 Burner Injector – Natural Gas Stereomatic, Type 7, Rs
1
/
8
4.9mm 1 8 716 140 223 0
80 E00-738 Burner Injector – Propane Stereomatic, Type 7, Rs
1
/
8
3.1mm 1 8 716 140 222 0
80 173 091 Burner Injector – Natural Gas Stereomatic, Type 7, 4.5mm dia. 1 8 716 140 208 0
80 E00-741 Burner Injector – Propane Stereomatic, Type 7, 2.78mm dia. 1 8 716 140 209 0
80 Burner Injector – Natural Gas Stereomatic, Type 7, 5.4mm dia. 8 716 104 457 01
80 Burner Injector – Propane Stereomatic, Type 7, 3.4mm dia. 8 716 104 458 01
81 375 697 Spark Electrode Assembly Buccleuch, Ref. BE/3462/SI 1 8 716 142 100 0
82 E01 612 Flame Sensor + Harness Buccleuch, Ref. BE/3461/SI 1 8 716 120 345 0
95 299 515 Ignition Harness Buccleuch, Ref. BE/3469/SI 1 8 716 120 229 0
61 299 352 Gas to Water Heat Exchanger Giannoni, Ref. PR22 323 003, D2107 1 8 716 142 800 0
61 Gas to Water Heat Exchanger Giannoni, Ref. PR26 326 1 8 716 102 675 0
42 299 353 Water to Water Heat Exchanger Giannoni, Ref. PVW 12 E, D2108 1 8 716 142 900 0
42 E00-711 Water to Water Heat Exchanger Giannoni, Ref. PVW 14 E 1 8 716 142 903 0
42 Water to Water Heat Exchanger Giannoni, Ref. PVW 16E 1 8 716 102 672 0
68 E00 716 Automatic Air Vent Intermes, Ref. 02.05.010 1 8 716 140 500 0
85 299 506 System Pressure Gauge Cewal, spec. D2111 1 8 716 142 300 0
40 375 699 Pressure Relief Valve Caleffi, Ref. 312439 1 8 716 142 404 0
29 173 006 Circulating Pump Grundfoss, Ref. 50 50 6500 1 8 716 143 108 0
25 173 001 Expansion Vessel Zilmet, Ref. 301010 1 8 716 142 500 0
34 173 005 Diverter Valve Giannoni, Ref. V37/OM/I/F/4/A 1 8 716 156 746 0
104 394 291 DHW Flow Regulator Type E – Blue 10 Litre 1 8 716 141 057 0
104 379 215 DHW Flow Regulator Type E – White 8 Litre 1 8 716 141 054 0
104 DHW Flow Regulator Type E – Red 12 Litre 1 8 716 141 061 0
105 378 416 Domestic Water Filter MPM, V3326 1 8 716 148 400 0
109 E01-840 Charging Link Assembly 1 8 716 120 320 0
84 E00-722 Circuit Board Bosch, Type Heatronic II 282 1 8 748 300 276 0
84 173 013 Circuit Board Bosch, Type Heatronic II AE 1 8 748 300 219 0
84 Circuit Board Bosch, Type Heatronic 1 8 748 300 430 0
96 299 516 Transformer ERA, Ref. BV 066-0188.0 1 8 747 201 248 0
65 E00-716 Fan Assembly WHS 1 8 716 120 282 0
65 299 497 Fan Assembly – RSF Sifan, REF. FFB.0226-016 1 8 716 120 034 0
65 Fan Assembly Fime GRO 1165 1 8 716 102 587 0
66 299 363 Air Pressure Sensing Probe WHS 1 8 716 141 000 0
129 E00-730 Differential Air Pressure Switch Huba, Ref. 605.99482 1 8 716 146 153 0
129 173 016
Differential Air Pressure Switch – RSF Huba, Ref. 605.99487 1 8 716 142 406 0
129 Differential Air Pressure Switch Huba, Ref. 6o5 1 8 716 104 461 0
60 375 696 Thermister Sensor Elmwood, Ref. 6655 - 9003 - 5 2 8 716 142 302 0
62 173 015 Overheat Thermostat Elmwood, Ref. 2455 R - 98 - 789 1 8 716 142 303 0
133 299 354
Combustion Chamber Insulation 24/28CDi WHS 1 7 716 192 204 0
133
Combustion Chamber Insulation 35CDi II WHS 1 7 716 192 224 0
134 299 355 Fibre Washer Pack WHS 1 7 716 192 205 0
135 299 356 ‘O’ Ring Pack WHS 1 7 716 192 207 0
136 299 357 Fuse Pack WHS 1 7 716 192 206 0
✓✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
✓✓
✓
✓
✓
✓
✓✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
✓
✓
✓
✓ ✓ ✓
✓ ✓ ✓
✓
✓
✓
✓ ✓ ✓
✓
✓
✓
✓ ✓ ✓
✓
✓
✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓
✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
Key G.C. No. Part Manufacturer’s Reference Qty WHS
No. Part No.
Appliance
24CDi 28CDi 35CDi
II
✓
✓ ✓ ✓
✓✓
E80-451
8 716 140 208 0
8 716 105 033 0
8 716 105 121 0
8 716 142 602 0
4.5mm
AC 23/05 3582
AC 23/05 3602
4.3mm dia

Worcester 35CDi II Specifications

General

Model	35CDi II
Output	35kW
Mounting	Wall-mounted
Max. DHW Output	35kW
Efficiency Rating	A
ErP Heating	A
ErP Water	A
Warranty	5 years
Fuel Type	Natural Gas
