13
Service clearances
Greenstar CDi Compact
ErP
- 6 720 813 277 (2014/09)
5 Service clearances
Your installer will have provided adequate space around the boiler for safety and servicing access.
Fig. 4 Service clearances
[*] Minimum clearances to removable door
[**] Minimum clearances required for servicing
[***] Height for either 60/100 flue or 80/125 flue
CAUTION: Restricted space.
The boiler may overheat.
▶ Do not restrict this space with the addition of cupboards, shelves etc. next to the boiler.
NOTICE: Combustible and corrosive materials:
Chemically aggressive substances can corrode the appliance and invalidate any guarantee.
▶ Do not store or use any combustible materials (paper, thinners, paints, propellants, cleaning agents etc.)
inside the cupboard containing the appliance or within the vicinity of the appliance.
1060/1100mm***
880mm
300mm
400mm
170/210mm***
600mm**
5mm
5mm
200mm
20mm*
6720646608-122.1Wo
