6.8 Screwing
It is advisable to use self-centering screws (e.g. Torx, cross recessed
head) as these will enable you to work safely and reliably. Always make
sure that the bit used is of the same size and shape as the screw. Set the
torque to suit the screw size as specified in the instructions.
6.9 LED lamp (Fig. 1/Item 9)
The LED lamp (9) can be used to additionally illuminate the area where
you want to screw or drill.
The LED lamp (9) will be lit automatically as soon as you press the ON/
OFF switch (4).
6.10 Switching between speed 1 and speed 2 (Fig. 8/Item 7)
You can work with a higher or lower speed depending on the position of
the selector switch. Change the gear only when the drill is at a standstill. If
you fail to observe this point, the gearing may be damaged.
8
7
2
1
WZAS_14_4_1_Li_UK_SPK7.indb 22 30.07.12 08:50
