Assembly
1. Insert the air hose connector into the open end of the
air inflator then tighten it by turning clockwise (Fig. 3).
2. To remove, turn the air hose connector counter-
clockwise and remove the air hose (Fig. 4).
3. Attach the Battery pack (Fig.5)
Hold the air inflator with one hand the battery pack (6) with the other.
Pull and slide battery pack into battery port, make sure the release button (7) on the front
side of the battery snap into place and battery is secure before beginning operation.
Assembly
Fig. 3
Fig. 4
Fig. 5
