7.3Adjusting the wheel guard (10) (see fig. C1-C7)
WARNING:Always ensure that the grinder is switched
off and the battery pack (6) is removed before making
any adjustments.
• The grinder must only be operated with the wheel guard
(10) installed.
WARNING: When using the angle grinder with a cutting
disc, a wheel guard for cutting (not included) must
be fitted prior to operation. Failure to do so may result in
serious injury.
This angle grinder is supplied with a wheel guard for grinding, to
be used with the grinding discs supplied. The size of the supplied
grinding discs are: 125mm diamater x 22.23mm bore x 6mm
thickness.
The supplied wheel guard for grinding is not suitable for cutting
discs.
NOTE: Before using, adjust the wheel guard (10) so that any flying
sparks or detached parts will not hit either the user or bystanders.
1) Take out the pin wrench (8) from the auxiliary handle (7).
2) Press in the spindle lock button (1) ensuring it is engaged and
keep it pressed in, then, loosen the outer flange (11) in an anti-
clockwise direction with the pin wrench (8).
3) Remove the outer flange (11), grinding disc (9) and the inner
flange (12).
4) Loosen the 3 screws a little, using a philips head screwdriver (not
supplied) in an anti-clockwise direction.
5) Hold the wheel guard (10) and rotate it to the required position.
NOTE: The notches must be located in each groove while
positioning.
