WORLD TECH ELITE 33061 - Drone and Transmitter Diagrams; Drone Component Identification; Transmitter Controls and Interface

4
DRONE DIAGRAM
TRANSMITTER DIAGRAM
*Speed Control Modes:
• Low Speed: Transmitter beeps once.
• High Speed: Transmitter beeps twice.
NOTE: Drone starts in the Low Speed Mode.
Press the HIGH SPEED GEAR button to toggle.
Rotor
Landing Skids
HD Picture/Video Camera
Landing
Skids
LED
Lights
BOTTOM OF DRONE
Power
Switch
Battery
Compartment
Left/Right Trim Adjustment
Smart Phone
Cradle
Power Switch
A Return
Camera
Power Indicator
Auto Pilot
Rudder
HD Picture/Video
Camera Mount
Throttle
Video
Camera Fine
Tuning
Speed Control
Follow Me
Orbit
GPS Switch
Forward/Backward
Trim Adjustment
