WorldWEIGH BWS - SPECIFICATION

BWS platform scales Technical Manual
- 2 -
1. SPECIFICATION
Model
BWS
BWS-E
Display
52mm LCD
1.2” LED
Housing
SST
Operating Temperature
-10°C - 40°C / 14°F - 104°F
Resolution
1/6000 (OIML Approved)
Key Pad
7 Keys
Power
AC Adaptor (12V/500mA)/ Battery (6V/4Ah)
Calibration
Automatic External
Interface
RS-232 Output Optional
Load cell drive Voltage
Max: 5V/150mA
Load Cells
Up to 4 load cell
ADC
Sigma Delta
ADC Update
≤1/10 second
Stabilization Time
One seconds typical
