1. AUXILIARY HANDLE
2. THREE SPEED SETTINGS
3. LOCK OFF SWITCH
4. BATTERY PACK
5. ON/OFF LEVER
6. SHAFT LOCKING KNOB
7. AUXILIARY HANDLE LOCKING CLAMP
8. SAFETY GUARD
9. EDGE GUIDE
10. LINE CUTTER
11. TRIMMER HEAD COVER (See Fig. I2)
12. CAP RELEASE LATCH (See Fig. I2)
13. SPOOL (See Fig. I2)
14. TRIMMER HEAD (See Fig. I2)
15. EYELET (See Fig. I2)
16. LINE FEED BUTTON (See Fig. I1)
Not all the accessories illustrated or described are included in standard delivery.
