Cordless Chainsaw EN
18
the pole saw.
Replacing Bar & Chain
Replace chain when cutters are too worn to sharpen
or when chain stops. Only use replacement chain
noted in this manual.
Inspect guide bar before sharpening chain. A worn
or damaged guide bar is unsafe. A worn or damaged
guide bar will damage chain. It will also make cutting
harder.
Fit the bar tensioning plate tab into the new bar by
tightening the screw clockwise. The tab protrusion (a)
must be fitted into the bar hole. (See Fig. Q)
SHARPENING SAW CHAIN
WARNING: Unplug chainsaw from power
source before servicing. Severe injury
or death could occur from electrical shock or
body contact with moving chain.
Cutting edges on chain are sharp. Use
protective gloves when handling chain.
Keep chain sharp. Your saw will cut faster and more
safely. A dull chain will cause undue sprocket, guide
bar, chain, and motor wear. If you must force chain
into wood and cutting creates only sawdust with few
large chips, chain is dull.
LUBRICATE SPROCKET
WARNING: Wear heavy duty gloves when
performing any maintenance or service
to this tool. Always unplug the tool before
performing any service or maintenance on this
tool.
NOTE: It is not necessary to remove the chain or bar
when lubricating the guide bar sprocket.
1. Clean the bar and sprocket
2. Using a grease gun, insert the tip of the gun
into the lubrication hole and inject grease until
it appears at the outside edge of the sprocket tip
(See Fig. R)
3. To rotate the sprocket pull the chain by hand
until the ungreased side of the sprocket is in
line with the grease hole. Repeat the lubrication
procedure.
For Battery tools
The ambient temperature range for the use and
storage of tool and battery is 0°C-45°C (32°F-113°F).
The recommended ambient temperature range for
the charging system during charging is 0°C-40°C
(32°F-104°F).
