12
Cordless Lawn Mower EN
14. CHARGE CORD
15. QUICKRELEASE BUTTON
16. SAFETY LOCKOUT BUTTON
17. SWITCH BUTTON FOR LED HEADLIGHT
18. CHARGE CORD INPUT
19. BATTERY INDICATOR BUTTON
20. SIDEDISCHARGE COVER SEE FIG. D2
21. SIDE DISCHARGECHUTE SEE FIG. D2
22. BATTERY PACK SEE FIG. F1
23. BLADE BOLT SEE FIG. R1
24. BLADE SEE FIG. R1
25. SPACER SEE FIG. R1
*Not all the accessories illustrated or described are
included in standard delivery.
TECHNICAL DATA
Type WG761 WG761.9 (7- designation of ma-
chinery, representative of Cordless Lawn Mower)
WG761 WG761.9
Voltage 80V Max. (4x20V Max.)**
No load speed 2800 /min
Deck width 53 cm
Cutting width 20’’ (51 cm)
Front wheel diameter 200 mm
Rear wheel diameter 250 mm
Cutting height 1-1/2’’~4” (40 – 100 mm)
Cutting height positions 7
Grass collection capacity 1.9 bushels (70 L)
Battery capacity 5.0 Ah (WA3571) /
Battery type Lithium-Ion
Charger Model WA3774 /
Charger rating Input: AC
220-240 V~50 Hz
Output: 20 V , 1 A
(each battery slot)
/
Charging time for a
single battery pack
(approx.)
5.0 Ah 5 hrs
/
Machine Weight 77.2 lbs
(35 kg)
70.6 lbs
(32 kg）
** Voltage measured without workload. Initial battery
voltage reaches maximum of 80 volts. Nominal voltage is
72 volts.
Each charging port is independent. The charging time for
four battery packs of the same capacity is equal to the
time for a single battery pack.
ACCESSORIES
WG761 WG761.9
Battery pack (WA3571) 4 /
Basecamp (WA3774)
(80V Power Source &
Charger)
1 1
Grass collection bag 1 1
Side-discharge kit 1 1
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to the
accessory packaging for further details. Store personnel
can assist you and offer advice.
OPERATION INSTRUCTION
NOTE: Read instruction handbook before
operation this machine.
INTENDED USE
This product is intended for domestic lawn mowing.
ASSEMBLY & OPERATION
ACTION FIGURE
ASSEMBLY
Lifting the handle bar
NOTE: Press and hold Quick-release
button during operation.
See Fig. A
Assembling the grass collection bag See Fig. B
