Worx WX333 User Manual

Rotary hammer EN
11
10
SYMBOLS OPERATING
INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for hammer drilling
in concrete, brick and stone as well as for light
chiseling work. It is also suitable for drilling without
impact in wood, metal, ceramic and plastic.
1. ADJUSTING THE AUXILIARY HANDLE
(See Fig. A )
For your personal safety we recommend using
the auxiliary handle at all times.
To adjust the handle, rotate the bottom of the
handle anti-clockwise and rotate the handle
around the hammer collar until the handle is
in the desired position. Tighten fully.
2. USING THE DEPTH GAUGE (See Fig. A)
The depth gauge can be used to set a constant
depth to the drill.
Rotate the locking screw on the top of the
handle anti-clockwise to loosen, insert the
depth stop into the handle. Adjust it to the
desired depth. Rotate the locking screw
clockwise to tighten.
3. FITTING BITS OR CHUCK (See Fig. B1)
Clean the bit shank and apply grease before
installing the bit. Hold the rotary grip, pull
back the lock sleeve and insert the bits or
chuck into the bit holder. Turn the bit and push
it in until a resistance is felt. The shaft drops
completely into the bit holder. Once you are
satisfied that it has been seated, release the
black lock sleeve. This would lock the bits or
chuck into position.
After installing, always make sure that the tool
or chuck is securely held in the bit holder by
trying to pull it out.
If the bits or chuck is not located well, repeat
the operation again.
4. REMOVE BITS OR KEY CHUCK
(See Fig. B1)
To remove the tool or chuck, pull back the lock
sleeve, hold and pull the tool or chuck out.
To reduce the risk of injury, user
must read instruction manual
Double insulation
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Waste electrical products should
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
Local Authority or retailer for
recycling advice.

Worx WX333 Specifications

General

Drilling	Yes
Chuck type	SDS Plus
Motor type	Brushed
Screwdriving	-
Product design	Pistol grip drill
Idle speed (max)	750 RPM
Chuck capacity (max)	- mm
Impact rate (high speed)	3700 bpm
Drilling diameter in wood (max)	40 mm
Drilling diameter in steel (max)	13 mm
Drilling diameter in concrete (max)	32 mm
Product color	Black, Orange, White
Cable length	2.8 m
Output power	1250 W
Power source	AC
AC input voltage	220 V
Impact energy (max)	5 J

Weight and Dimensions

Depth	180 mm
Width	490 mm
Height	350 mm
Weight	6100 g
