Worx WX333 User Manual

Rotary hammer EN
7
6
1. LOCKING SLEEVE
2. DEPTH GAUGE
3. GREASE BOX COVER
4. ON/OFF SWITCH
5. HAMMER OR DRILLING ACTION SELECTOR SWITCH
6. HAMMER OR CHISEL ACTION SELECTOR SWITCH
7. VARIABLE SPEED CONTROL
8. SDS DRILL BITS*
9. SPANNER
10. KEY CHUCK WITH ADAPTOR, CHUCK KEY*
11. PLASTIC CONTAINER GREASE*
12. DUST COVER*
13. CHISELS (POINT & FLAT)*
14. AUXILIARY HANDLE
TECHNICAL DATA
Type WX333 (330~359-designation of machinery, representative of Rotary hammer)
Voltage 220-240V~50/60Hz
Power input 1250W
No load speed 0-750/min
Impact rate 0-3700/min
Impact energy 5.0J
Chuck type SDS-plus
Max drilling capacity Steel 13mm
Masonry 32mm
Wood 40mm
Protection class
/II
Machine weight 6.1kg
*Not all the accessories illustrated or described are included in standard delivery.

Worx WX333 Specifications

General

Drilling	Yes
Chuck type	SDS Plus
Motor type	Brushed
Screwdriving	-
Product design	Pistol grip drill
Idle speed (max)	750 RPM
Chuck capacity (max)	- mm
Impact rate (high speed)	3700 bpm
Drilling diameter in wood (max)	40 mm
Drilling diameter in steel (max)	13 mm
Drilling diameter in concrete (max)	32 mm
Product color	Black, Orange, White
Cable length	2.8 m
Output power	1250 W
Power source	AC
AC input voltage	220 V
Impact energy (max)	5 J

Weight and Dimensions

Depth	180 mm
Width	490 mm
Height	350 mm
Weight	6100 g
