Worx WX425 User Manual

Circular saw EN
7
6
1. SOFT GRIP HANDLE
2. LOCK OFF SWITCH
3. LASER ON/OFF SWITCH (WX426)
4. ON/OFF SWITCH
5. AUXILIARY HANDLE
6. SPINDLE LOCK BUTTON
7. BASE PLATE ANGLE SCALE
8. BASE PLATE BEVEL LOCK
9. PARALLEL GUIDE
10. BASE PLATE
11. LOWER GUARD
12. SAW BLADE*
13. BLADE BOLT
14. LOWER GUARD LEVER
15. VACUUM ADAPTER
16. DEPTH OF CUT LOCK LEVER
17. HEX KEY STORAGE AREA
18. PARALLEL GUIDE LOCK KNOB (See Fig. D)
19. LASER GUIDE (See Fig. K)(WX426)
20. BEVELTRAC
TM
(See Fig. D2)(WX425)
* Not all the accessories illustrated or described are included in standard delivery.

Worx WX425 Specifications

General

Blade diameter	160 mm
Idle speed (max)	5000 RPM
Sound power level	93 dB
Bevel capacity (max)	45 °
Cutting depth (45º)	38 mm
Cutting depth (90º)	55 mm
Sound pressure level	82 dB
Sound level uncertainty	3 dB
Vibration level (wood cutting)	4.36 m/s²
Vibration level uncertainty (wood cutting)	1.5 m/s²
Input power	1200 W
Power source	AC
AC input voltage	230 - 240 V
AC input frequency	50 / 60 Hz
Motor type	Brushed
Product color	Grey, Orange, Stainless steel, White
Built-in light	No
Protection class	II
Dust extraction port	Yes
Suitable for materials	Wood

Weight and Dimensions

Width	340 mm
Weight	3500 g
