Electric Circular Saw EN
8
1. LOCK OFF BUTTON
2. SOFT GRIP HANDLE
3. HEX KEY
4. ON/OFF SWITCH
5. SPINDLE LOCK BUTTON
6. LOWER BLADE GUARD
7. LOWER GUARD LEVER
8. FIXED UPPER GUARD
9. DUST EXTRACTION OUTLET
10. VACUUM ADAPTER
11. DEPTH ADJUSTMENT LEVER
12. BASE PLATE
13. SAW BLADE (See Fig. A)
14. INNER FLANGE (See Fig. A)
15. BLADE BOLT (See Fig. A)
16. PARALLEL GUIDE
17. PARALLEL GUIDE CLAMPING FIXTURE
18. BEVEL ADJUSTMENT LEVER
19. OUTER FLANGE (See Fig. A)
20. LASER
21. LASER ON-OFF SWITCH
22. LASER BATTERIES (Two) (See Fig. E2)
23. BLADE ALIGNMENT INDICATOR
Not all the accessories illustrated or described are included in standard delivery.
