Compact Circular Saw EN
1. SAFETY SWITCH
2. ON/OFF TRIGGER
3. SOFT GRIP HANDLE
4. HEX KEY
5. BLADE GUARD LEVER
6. BLADE GUARD
7. BASE PLATE
8. PARALLEL GUIDE
9. BLADE ALIGNMENT INDICATOR
10. PARALLEL GUIDE CLAMPING FIXTURE
11. BEVEL ADJUSTMENT LEVER
12. DUST EXTRACTION OUTLET
13. VACUUM ADAPTER
14. FIXED UPPER BLADE GUARD
15. SPINDLE LOCK BUTTON
16. DEPTH ADJUSTMENT LEVER
17. BLADE BOLT
18. OUTER FLANGE
19. SAW BLADE
20. INNER FLANGE
Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Voltage 230–240V~50Hz
Rated power 400W
No load (rated) speed 3800/min
Blade size
TCT blade 120mm X 1.2mm X 9.5mm
HCS blade 115mm X 1.3mm X 9.5mm
Diamond disc 115mm X 1.6mm X 9.5mm
Bevel capacity 0-45°
Cutting capacity Cutting Depth at 90° 46mm
Cutting Depth at 45° 30mm
Arbor Size 9.5mm
Recommended maximum material thickness
Wood 46mm
Aluminum 2.5mm
PVC pipe (diameter) 46mm
Tile 12mm
Sheet steel 0.5mm
Protection class
/ll
Bare tool weight 2kg
Spindle thread size M6
Saw blade thickness
TCT blade 0.8mm
HCS blade 0.8mm
Diamond disc 0.8mm
