13
Compact Circular Saw
WX437
WX437.X
COMPONENT LIST
1. SOFT GRIP HANDLE
2. HEX KEY
3. LOCK OFF BUTTON
4. ONOFF SWITCH
5. FIXED UPPER GUARD
6. LOWER GUARD LEVER
7. BASE PLATE
8. LOWER BLADE GUARD
9. SPINDLE LOCK BUTTON
10. VACUUM ADAPTER
11. DEPTH ADJUSTMENT LEVER
12. PARALLEL GUIDE
13. SAW BLADE*
14. INNER FLANGE
15. BLADE BOLT
16. BEVEL ADJUSTMENT LEVER
17. DUST EXTRACTION OUTLET
18. PARALLEL GUIDE CLAMPING FIXTURE
19. OUTER FLANGE
20. LASER GUIDE
21. LASER ONOFF SWITCH SEE FIG. D1
22. LASER BATTERIES TWO SEE FIG. E2
* Not all the accessories illustrated or described are
included in standard delivery.
TECHNICAL DATA
Type WX437 WX437.X (4-designation of machinery,
representative of Saw)
WX437 WX437.X**
Voltage 230-240V~50/60Hz
Rated Power 800W
No load (rated) speed 4700 /min
Blade size
TCT blade (WA5100) 120 mm X1.5mmX 9.5mm X 24T
HCS blade (WA8302) 115 mm X1.2mmX 9.5mm X 60T
Abrasive cutting disc
(WA5048)
115 mmX1.6mm X9.5mm X 60G
Cutting capacity
Cutting Depth at 90°
Cutting Depth at 45°
42.5mm
28.5mm
Bevel capacity 0-45°
Arbor size
9.5 mm
Laser battery model
no.
LR44 1.5V
Protection class
/II
Bare tool weight 2.3kg
** X=1-999,A-Z,M1-M9 there are only used for different
customers, there are no safe relevant changes between
these models
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to the
accessory packaging for further details. Store personnel
can assist you and offer advice.
NOISE INFORMATION
CUTTING WOODCUTTING
METAL)
A weighted sound pressure L
pA
=88 dB(A)
A weighted sound power L
wA
= 99 dB(A)
K
pA
&K
wA
3 dB(A)
Wear ear protection
