Circular saw with laser EN
10
machine on the face side of the motor housing.
REMOVING
Press the spindle lock button (10) and keep it
depressed.
• The spindle lock button (10) may be actuated only
when the saw blade is at a standstill.
Loosen the blade bolt (15) with the hex key (20).
Remove the outer flange (12). Tilt back the lower
blade guard (13) and hold it firmly with the lower
guard lever (16). Remove the saw blade (14).
MOUNTING
Clean the saw blade and all the clamping parts to be
assembled. Tilt back the lower blade guard (13) and
hold it firmly with the lower guard lever (16). Place
the saw blade onto the inner flange (22). Assemble
the outer flange (12) and the blade bolt (15). Use the
hex key (20) to tighten the bolt (15) with 1/4 turn,
more than finger tight.
• Take care that the mounting positions of the
inner flange (22) and outer flange (12) are
correct.
• When mounting: Ensure that the cutting
direction of the teeth (direction of arrow
on saw blade) and the direction-of-rotation
arrow on the blade guard match.
4. DUST/CHIP EXTRACTION (See Fig. H)
Fasten the vacuum adapter (17) onto the dust
extraction outlet until it latches. Additionally fasten
the vacuum adapter (17) to the fixed guard with the
two screws. Directly connect a suitable vacuum hose
to the adapter.
• The vacuum adapter must not
be mounted when no external dust
extraction is connected. Otherwise there
is danger of the extraction system becoming
clogged.
Clean the vacuum adapter regularly to ensure
optimum dust extraction. The vacuum cleaner must
be suitable for the material to be worked.
5. HEX KEY STORAGE (See Fig. I)
The hex key is stored at the rear of the circular saw.
Put the key back when not in use.
6. USING THE LASER GUIDE (See Fig. J)
WARNING: Never stare directly into the laser
beam and never point the beam at anybody.
The laser beam energy is extremely harmful to
human eyes.
Push the laser on/off switch (3) to ‘I’ to turn the laser
on. The laser device can provide a beam in the same
plane as the blade, which projects onto the workpiece
to generate a line. The saw blade can be directed to
follow the line in order to align the cut. Either straight
cutting or bevel cutting, it will make more precise
movement during operation.
Push the laser on/off switch (3) to ‘0’ to turn the laser off.
NOTE: Clean the laser generator periodically.
7. ACCESSIBLE MOTOR BRUSH REPLACEMENT
(See Fig. K)
There are two replaceable motor brushes which can
be easily accessed on either the front or back of the
motor housing.
WARNING: Disconnect the plug
from the power source before making any
adjustments, changing accessories, or storing
power tools. Such preventative safety measures
reduce the risk of starting the power tool accidentally.
ATTENTION: When servicing a tool,
always use only genuine replacement
parts
1. Locate the plastic motor brush access caps on
either the front or back of the motor housing.
2. Remove the threaded access cap using a flat
head screwdriver and turn in a counter-clockwise
rotation to loosen. Do not apply excessive force
as this may damage the access plug.
3. Remove the old motor brush.
4. Insert the new motor brush making sure that it is
completing inserted into the brush holder.
5. Replace the access cap with the flat-head
screwdriver turning clockwise to tighten.
WORKING HINTS FOR YOUR
CIRCULAR SAW
If your power tool becomes too hot, please run your
circular saw no load for 2-3 minutes to cool the
motor. Avoid prolonged usage at very low speeds.
Protect saw blades against impact and shock.
Excessive feed significantly reduces the performance
capability of the machine and reduces the service life
of the saw blade. Sawing performance and cutting
quality depend essentially on the condition and the
tooth form of the saw blade. Therefore, use only
sharp saw blades that are suited for the material to
be worked.
MAINTENANCE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Your tool requires no additional lubrication or
maintenance. There are no user serviceable parts
in your tool. Never use water or chemical cleaners
to clean your tool. Wipe clean with a dry cloth.
Always store your tool in a dry place. Keep the motor
ventilation slots clean. Occasionally you may see
sparks through the ventilation slots. This is normal
and will not damage your power tool.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
