8 SERVICE WORK ON THE CHASSIS
11
8.1 Raising the motorcycle with a lift stand
Note
Danger of damage The parked vehicle can roll away or fall over.
– Park the vehicle on a firm and level surface.
401942-01
– Raise the motorcycle at the frame underneath the engine.
Neither wheel is in contact with the ground.
– Secure the motorcycle against falling over.
8.2 Removing standard fork legs
Preparatory work
– Raise the motorcycle with a lift stand. ( p. 11)
– Remove the front wheel. ( p. 15)
A00142-10
Main work
–
Remove screws
1
and take off the clamp.
–
Remove screws
2
and spacers.
– Allow the brake caliper and brake line to hang loosely to the
side.
Info
Do not kink the brake line.
Do not operate the hand brake lever when the brake
caliper is removed.
A00144-11
–
Loosen screws
3
. Remove the left fork leg.
–
Loosen screws
4
. Remove the right fork leg.
