10 TECHNICAL DATA
21
10.1 Fork
Fork article number 43.18.2R.04
Fork WP AER 43 Cone Valve Fork
Compression damping 16 clicks
Rebound damping 18 clicks
Fork length 850 mm (33.46 in)
Oil capacity external mechanism
right
100 ml (3.38 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 22)
Oil capacity external mechanism
left
100 ml (3.38 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 22)
Oil capacity, right cartridge 150 ml (5.07 fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 22)
Grease capacity, left cartridge 11 ml (0.37 fl. oz.) Multi-purpose grease
(00062010051) ( p. 23)
10.2 Chassis tightening torques
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, axle clamp M8 15 Nm (11.1 lbf ft)
Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 20 Nm (14.8 lbf ft)
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft)
