BASE UNIT
600 - 1000 Hob
2/3 Drawer
Carcass Assembly
For Internal Use: FI.WR.INS.058_WKIN00112_BASE_600-1000_2-3Drw_Hob_Rev1.indd Page 4
Fixing
clip
& (Q)
Y & L
(F) x8
Wooden Dowel
(G) x6
Cam Dowel
(Expanding)

Cam Lock
(K) x4
30mm
Screw
(L) x12
15mm
Screw
(M) x4
Cover
Cap
Panel B
x2 End Panel
Panel E
x1 Rail
Panel C
x1 Base Panel
Shelf
x1
Sink
Rail
x1
Legs
x4 or 5
as req’d
Frontal
(Packed separately)
x1 or 2 as Req’d
Panel A
x1 Back Panel
REQUIRED TOOLS
NOT to be used
with CAM DOWEL
& CAM LOCK
sink rail +
screws



BEFORE YOU START
INSTALLATION

PERFORMED BY A
COMPETENT
PERSON ONLY.

BE DANGEROUS
IF INCORRECTLY
INSTALLED
