Wren TOWER UNIT - Carcass Construction; Carcass Components and Hardware

REQUIRED TOOLS
NOT to be used
with CAM DOWEL
& CAM LOCK
For Internal Use: FI.WR.INS.043_WKIN00143_TOWER_600_2AppIncDr+Drw_Rev3.indd
Page 3
TOWER UNIT
600 Double Appliances
Inc Dr+Drw
Assembly Guide
BEFORE YOU START
INSTALLATION
SHOULD BE
PERFORMED BY A
COMPETENT
PERSON ONLY.
THIS PRODUCT COULD
BE DANGEROUS
IF INCORRECTLY
INSTALLED
(F) x24
Wooden
Dowel
(L) x24
15mm
Screw
(G) x20
Cam Dowel
(Expanding)
(H) x20
Cam lock
(M) x4
Cover Cap
(K) x16
30mm
Screw
(R) x30
19mm
Screw
(N) x2
Door Buer
(U) x2
Fixing Plate
(Z) x12
Shelf Peg
Plastic
LGE L BRACKET
x2
SML L BRACKET
(FF) x4
HINGE MOUNTING PLATE
x2 Inc Screws
HINGE
x2 (Inc Screws)
Panel B
x2 End Panel
Panel A
x2 Back Panel
Panel E
x2 Rail
Appliance Shelf
x1
Legs
x5
Frontal
x1 (Packed separately)
Panel C
x24 End Panel
600+450 Appliance
Inc 1 Door + 1 Drawer
