Bulletin # 056
5 Pages
May 10, 2006
Installation Instructions for Replacement Heat Shield
WMI part number: 91410026
Step One: Remove the four nuts on the exhaust ports with a 12mm socket and the upper
mounting bracket nut and bolt using two 1/2-inch wrenches
Step Two: After removing muffler from engine, remove the heat shield if it is still attached to
the muffler can. This can be done using Tin-Snips (as shown below). Be careful not to
damage or puncture the muffler can in the removal process.
