Bulletin # 056
5 Pages
May 10, 2006
Step Three: Install the replacement heat shield by directing the exhaust port mount under the
muffler header bracket and aligning the upper mounting bracket through the oblong hole in the
shield.
Step Four: Thoroughly remove old gasket material and clean affected areas. Using new
exhaust gaskets (included with heat shield), remount the muffler can with exhaust studs going
through the heat shield. Align the upper mounting bracket of the heat shield such that the
muffler tailpipe is centered on the side and not touching the heat shield.
19
