5
V3307-DI-T-E2B, WSM
SPECIFICATIONS
SPECIFICATIONS
* The specification described above is of the standard engine of each model.
* Conversion Formula : HP = 0.746 kW, PS = 0.7355 kW
W1028103
Model V3307-DI-T-E2B
Number of Cylinder 4
Type Vertical, water-cooled, 4-cycle DI diesel engine
Bore × Stroke 94.0 × 120 mm (3.70 × 4.72 in.)
Total Displacement 3331 cm
3
(203.3 cu.in.)
ISO Net Continuous
47.1 kW / 2600 min
-1
(rpm)
(63.2 HP / 2600 min
-1
(rpm))
ISO / SAE Net Intermittent
53.7 kW / 2600 min
-1
(rpm)
(72.0 HP / 2600 min
-1
(rpm))
SAE Gross Intermittent
55.4 kW / 2600 min
-1
(rpm)
(74.3 HP / 2600 min
-1
(rpm))
Maximum Bare Speed 2820 min
-1
(rpm)
Minimum Bare Idling Speed 775 to 825 min
-1
(rpm)
Combustion Chamber Reentrant Type, Center Direct Injection Type (E-CDIS)
Fuel Injection Pump Bosch PFR4KZ Type Mini Pump
Governor All speed mechanical governor
Direction of Rotation Counter-clockwise (Viewed from flywheel side)
Injection Nozzle Bosch P Type
Injection Timing 0.0087 rad (0.50 °) after T.D.C.
Firing Order 1-3-4-2
Injection Pressure
1st stage 18.63 MPa (190.0 kgf/cm
2
, 2702 psi),
2nd stage 22.56 MPa (230.0 kgf/cm
2
, 3271 psi),
Compression Ratio 20.0
Lubricating System Forced lubrication by trochoid pump
Oil Pressure Indicating Electrical Type Switch
Lubricating Filter Full Flow Paper Filter (Cartridge Type)
Cooling System Pressurized radiator, forced circulation with water pump
Starting System Electric Starting with Starter
Starting Motor 12 V, 3.0 kW
Starting Support Device By Glow Plug in Combustion Chamber
EGR None
Battery 12 V, 120 AH equivalent
Charging Alternator 12 V, 540 W
Fuel
Recommended fuels vary depending on the contents of the emission control regulations, the ambient
temperature, and the fuel specifications. Therefore, please refer to the detailed description on page
G-6.
Lubricating Oil
Class CF lubricating oil as per API classification is recommended.
For details on recommended lubricating oils, see page G-6 and page G-9.
Lubricating Oil Capacity 11.2 L (2.96 U.S.gals)
Weight (Dry) 271 kg (597 lbs)
KiSC issued 01, 2009 A
