wsm V3307-DI-T-E2B - Torque Specs: Special Fasteners

S-13
V3307-DI-T-E2B, WSM
ENGINE
[2] TIGHTENING TORQUES FOR SPECIAL USE SCREWS, BOLTS AND
NUTS
NOTEQ
• For “*” marked screws, bolts and nuts on the table, apply engine oil to their threads and seats before
tightening.
• The letter “M” in Size x Pitch means that the screw, bolt or nut dimension stands for metric. The size is
the nominal outside diameter in mm of the threads. The pitch is the nominal distance in mm between two
threads.
W1013236
Item Size x Pitch N·m kgf·m lbf·ft
Glow lead mounting nut M4 x 0.7 0.98 to 1.7 0.10 to 0.18 0.73 to 1.3
Glow plug M8 x 1.0 7.7 to 9.3 0.78 to 0.95 5.7 to 6.8
Cylinder head cover screw M6 x 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
Injection pipe retaining nut M12 x 1.5 23 to 36 2.3 to 3.7 17 to 26
Oil switch taper screw R 1/8 15 to 19 1.5 to 2.0 11 to 14
Injection pump unit mounting nut M8 x 1.25 18 to 20 1.8 to 2.1 13 to 15
Drain plug M22 x 1.5 45 to 53 4.5 to 5.5 33 to 39
Oil pipe 1 mounting screw M10 x 1.25 16 to 19 1.6 to 2.0 12 to 14
Thermo valve R 3/8 30 to 39 3.0 to 4.0 22 to 28
Nozzle holder clamp screw M8 x 1.25 24 to 27 2.4 to 2.8 18 to 20
Overflow pipe assembly retaining screw M6 x 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
*Lubricating oil pipe mounting screw M10 x 1.25 16 to 19 1.6 to 2.0 12 to 14
Governor housing mounting screw M6 x 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
Lock nut M5 x 0.8 2.9 to 4.0 0.29 to 0.41 2.1 to 2.9
Injection pump assembly mounting screw M8 x 1.25 24 to 27 2.4 to 2.8 18 to 20
Injection pump assembly mounting nut M8 x 1.25 18 to 20 1.8 to 2.1 13 to 15
Governor weight mounting nut M12 x 1.25 63 to 72 6.4 to 7.4 47 to 53
Fuel camshaft stopper mounting screw M6 x 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
Fuel camshaft bearing stopper mounting
screw
M6 x 1.0 3.9 to 4.2 0.39 to 0.43 2.9 to 3.1
*Crankshaft screw M16 x 1.5 255 to 274 26.0 to 28.0 188 to 202
Relief valve retaining screw M22 x 1.5 69 to 78 7.0 to 8.0 51 to 57
*Flywheel screw M12 x 1.25 98.1 to 107 10.0 to 11.0 72.4 to 79.5
Camshaft set screw M8 x 1.25 24 to 27 2.4 to 2.8 18 to 20
Balancer shaft set screw M8 x 1.25 24 to 27 2.4 to 2.8 18 to 20
Starter’s terminal B mounting nut M8 x 1.25 9.8 to 11 1.0 to 1.2 7.3 to 8.6
Alternator pulley nut M24 58.4 to 78.9 5.95 to 8.05 43.1 to 58.2
Oil pump cover screw M6 7.9 to 9.3 0.80 to 0.95 5.8 to 6.8
KiSC issued 01, 2009 A
