wsm V3307-DI-T-E2B - Servicing Specifications: Engine Body

S-5
V3307-DI-T-E2B, WSM
ENGINE
2. SERVICING SPECIFICATIONS
ENGINE BODY
W1185533
Item Factory Specification Allowable Limit
Compression Pressure 3.92 MPa /
250 min
−1
(rpm)
40.0 kgf/cm
2
/
250 min
−1
(rpm)
569 psi /
250 min
−1
(rpm)
2.90 MPa /
250 min
−1
(rpm)
29.6 kgf/cm
2
/
250 min
−1
(rpm)
421 psi /
250 min
−1
(rpm)
Variance Among Cylinders – 10 % or less
Valve Clearance (Cold) 0.13 to 0.17 mm
0.0052 to 0.0068 in.
–
Top Clearance 0.60 to 0.80 mm
0.024 to 0.031 in.
–
Cylinder Head Surface Flatness – 0.05 mm
0.002 in.
Valve Recessing (Intake and Exhaust) 0.65 to 0.85 mm
0.026 to 0.033 in.
1.20 mm
0.0472 in.
Valve Stem to Valve Guide (Intake and
Exhaust)
Valve Stem
Valve Guide
Clearance
O.D.
I.D.
0.055 to 0.085 mm
0.0022 to 0.0033 in.
6.960 to 6.975 mm
0.2741 to 0.2746 in.
7.030 to 7.045 mm
0.2768 to 0.2773 in.
0.10 mm
0.0039 in.
–
–
Valve Face (Intake and Exhaust) Angle 0.79 rad
(45 °)
–
Valve Seat (Intake and Exhaust) Angle
Width
0.79 rad
(45 °)
3.3 to 3.6 mm
0.13 to 0.14 in.
–
–
Intake Valve Timing Open
Close
0.24 rad (14 °)
before T.D.C.
0.70 rad (40 °)
after B.D.C.
–
–
Exhaust Valve Timing Open
Close
0.87 rad (50 °)
before B.D.C.
0.24 rad (14 °)
after T.D.C.
–
–
Valve Spring (Intake and Exhaust) Tilt
Free Length
–
35.1 to 35.6 mm
1.39 to 1.40 in.
1.0 mm
0.039 in.
34.6 mm
1.36 in.
KiSC issued 01, 2009 A
