S-14
V3307-DI-T-E2B, WSM
ENGINE
W1335256
Item Size x Pitch N·m kgf·m lbf·ft
Rocker arm bracket screw M10 x 1.25 49 to 55 5.0 to 5.7 37 to 41
*Cylinder head mounting screw M14 x 1.5 187 to 196 19.0 to 20.0 138 to 144
Injection pump gear mounting nut
(left-handed screw)
M16 x 1.5 -LH 138 to 158 14.0 to 16.0 102 to 115
Oil cooler joint screw M20 x 1.5 40 to 44 4.0 to 4.5 29 to 32
Front cover mounting screw (7T) M8 x 1.25 24 to 27 2.4 to 2.8 18 to 20
Front cover mounting screw (10T) M8 x 1.25 30 to 34 3.0 to 3.5 22 to 25
Flywheel housing mounting screw (9T) M12 x 1.25 103 to 117 10.5 to 12.0 76.0 to 86.7
Idle gear mounting screw (10T) M8 x 1.25 30 to 34 3.0 to 3.5 22 to 25
*Connecting rod screw M9 x 1.0 69 to 73 7.0 to 7.5 51 to 54
*Crankcase 2 mounting screw M14 x 1.5 138 to 147 14.0 to 15.0 102 to 108
Crankcase 2 flange screw (9T) M10 x 1.25 59 to 63 6.0 to 6.7 44 to 47
To Next Page
