CRD-XP
CRD-XP_2006-04_EN Subject to technical changes Page 7 of 16
Advanced level: Digital inputs
No. Parameter Plant Min. Max. Description
P50
Digital
input 1
3 0 3
0: direct alarm
Zero current principle, direct alarm
on loss of current at the input
1: delayed alarm
Zero current principle, delayed alarm
on loss of current at the input
setting of delay time with P44
2: external defrost trigger
start of defrost either by button
or an external defrost timer
3: Cold location off
Control, temperature monitoring and probe monitoring
inactive, alarms are suppressed,
communication remains active, no messages via remote
data transmission
P51 Status
input 1
OFF OFF ON
Voltage status at digital input 1
(independent of selected function)
P52
Digital
input 2
0 0 2 0: Door contact
When the cold room is entered, fan and
evaporator solenoid switch off for a maximum of 15 mins.
Alarm after alarm delay
1: Day signal
Signals day operation,
set value shift for night operation
2: Shock freeze
The desired sharp freezing temperature is preset via P14. It
is controlled on the sharp setpoint. After the function is
ended and the sharp temperature is reached, forced
defrosting is performed; only when this is completed does
the device return to normal operation. During sharp
freezing, defrosting is not started.
3: Cooler off
Control, temperature monitoring and probe monitoring
inactive, alarms are suppressed,
communication remains active, no messages via remote
data transmission
4: 2
nd
setpoint
Control to the 2nd setpoint The 2nd setpoint is preset via
P14 (sharp set value).
P53 Status
input 2
OFF OFF ON Voltage status at digital input 2
(independent of selected function)
Advanced level: Probe parameters
No. Parameter Plant Min. Max. Description
P54
Operating mode
1 1 2 1: Control with one probe F1
2: No control
3: Weighted control with probes F1 and F2
4: Heating/cooling with one probe F1
P55 Not used
P56 Not used
P57 Adjustment to
Reg/Control probe F1
0K -10K +10K Calibration for control probe F1
Depending on probe arrangement, an adjust may be
necessary. Reading and adjustment value amount to the
actual probe value.
P58 Adjustment to
limit probe F2
0K -10K +10K Calibration for limit probe F2
(See P57)
P59 Not used
Advanced level: Display
No. Parameter Plant Min. Max. Description
P60 Displayed temperature P00 P00 P03 Standard display without operation
P61 Display resolution 0.1K 0.1K 1K
Alternatively, resolution of display 0, 1K or 1K.
