GENERAL WARNINGS
1. Use only manufacturer-approved DC power supply for external power source.
2. Use only manufacturer-approved battery for backup power source.
3. Ambient temperature not to exceed 0° C to 40° C.
4. Remove both the external power and the battery power supplies when performing maintenance
or upgrading equipment.
11-598-CC COMMAND CENTER PACK LIST
(1) Command Center enclosure p/n: 11-598-CC
(1) Battery p/n: SP12-9
(1) Battery cable p/n: 10049004
(1) Power supply assembly with power cord p/n: 10049005
11-10044346 FXS LINE CARD KIT PACK LIST
(1) FXS line card p/n: 11-701
(2) Card guide p/n: CBG-2-01
(2) Screw terminal plug p/n: 284506-2
11-10044347 2FXS LINE CARD KIT PACK LIST
(1) 2FXS line card p/n: 11-10002047
(2) Card guide p/n: CBG-2-01
(2) Screw terminal plug p/n: 284506-2
DESCRIPTION AND INTENDED USE
The Wurtec S3 Command Center is a telecommunications device capable of placing and connecting
calls between emergency elevator telephones and services on a PSTN. The Wurtec S3 Command
Center along with the Wurtec S3 Communicator emergency elevator telephones are designed to fulfill
the communications safety requirements for elevators as described in the ASME A17.1 elevator safety
code.
The S3 Command Center is intended to be installed and operated in a temperature-controlled, low-
humidity, low-ambient audible noise environment that is protected from dirt and airborne particles.
INSTALLATION TOOLS REQUIRED
1. 3/32” slot screwdriver
2. Wire strippers/cutters – typically 24-22 AWG dependent on cable used at installation site
PROTECTIVE GEAR REQUIRED
1. Safety glasses
2. ESD strap
