Gas cartridge (g. III)
I nserting the gas cartridge
Warning
Remove the batter from the device
before inserting the gas cartridge.
■ Actuate the unlocking mechanism as
shown in the gure and fold up the cover of the
intake slot [2].
■ Insert the gas cartridge with the valve head
facing the intake slot.
■ Close the cover [2].
Warning
Small amounts of combustible gas
may escape when the gas cartridge is
inserted.
Do not breath in gas, do not smoke. Keep it away
from naked ames or sparks.
If the smell of gas remains perceptible after the gas
cartridge has been inserted, remove the gas car
-
tridge immediately and identify the cause.
Note
The gas cartridge is not emptied com
-
pletely. There is always a small amount
of residual gas (pressure gas) in the
gas cartridge.
Loading the magazine (g. IV)
You can insert up to four magazine strips with 10
pins each in the magazine.
■ Insert the magazine strip [15] as shown in the
gure.
■ Draw the follower [11] to the stop and back
again until it is in contact with the magazine
strips [15].
■ To remove the magazine strip pull back the fol-
lower [11]. Actuate the release lever [12] and
draw back the follower [11]. Actuate the locking
mechanism [16] and remove the magazine strip.
Removing blockages
■ Remove the battery and the gas cartridge.
■ Remove the magazine strip.
■ Open the magazine lock [8] and remove the
magazine.
■ Eliminate the blockage.
■ Then insert the magazine.
■ Lock the magazine lock [8].
Substrate and separations
Caution
Pins may not be driven in unsuitable materials or
components.
Recommended substrate
Check the substrate thickness. The minimum pen-
etration depth of the driving pin and the minimum
strength of the surface must be maintained. This
ensures the secure hold of the fastening.
Substrate Penetra-
tion depth
Minimum
thickness
Concrete (DIN 1045,
C10/15 - C 40/50)
18 - 25 mm 100 mm
Calcium silicate approx. 32 m 100 mm
Steel 5 mm or
greater
5 mm or
greater
Solid brick 15 -32 mm 100 mm
Minimum distance of the substrate
from centres and edges (see also the
provisions of the German BGV D9
2002)
The distance to free edges must be sucient to
prevent the pin from lateral penetration.
Do not drive in the pins too close in order to prevent
them from comming loose from their xing position
in case the material breakes out or tears away.
Brick-
work
Concrete,
Steel
reinforced
concrete
Steel
Minimum
centre-to-cen-
tre distance
5 cm 5 cm 3-fold pin
shaft Ø
Minimum
edge distance
10-fold pin
shaft Ø
10-fold pin
shaft Ø
5-fold pin
shaft Ø
