Intended use
This device is intended to be used for ring pins
(fasteners) into concrete, full block calcium silicate,
full bricks and steel using the original Würth system
parts.
Any other use is considered improper.
The user is responsible for damage resulting from
improper use.
+49 1805-60 65 69 (14 Cent/min).
Device Data
Art. 0864 90 3
Firing power (max.) 1000/h
Pin length x pin - Ø (max.) 40 x 3.7 mm
Magazine capacity 42 pins / 22 pins
Dimensions (height x length
x width)
365 x 435 x 124
mm
Weight 3.7 kg
Gas cartridge item no. 0864 900 500
Capacity 80 ml
Substance - Propylene
- But-1-ene
Hazard class 2.1 UN 1965
Max. ambient temperature 50°C
Energy reserve approx. 1100
ring processes
Mains adapter
Input voltage / current 100–
240 V AC / 0.4 A
Output voltage / current 10 V/ 0.8 A
Charging time
- Discharging the battery 120 min
- rst use 24 h
Battery NiMH
Nominal voltage 6 V DC
Capacity 1.5 Ah
Ambient temperature 5 - 50 °C
Energy reserve with fully
charged battery
approx. 3000
ring processes
Method of functioning
The device has a combustion drive with explosive
gas mix. By ignition of the gas mix, the piston is
actuated and drives in the pin. Exhaust gas and
noise emissions, which may be hazardous to health,
are generated during the combustion process.
Adhere to the stipulated safety instructions.
Battery and charger (g. II)
Charge the battery
The battery must be charged for 24 hours prior to
rst use and when it has not been in use for a longer
period of time to achieve full capacity.
■ To remove the battery [6] from the device, fully
push the two release buttons [5].
■ Plug the power plug into the socket and the
charging plug into the socket of the charger.
3 The charging process starts as soon as the
battery [6] is set in the charging cradle. The
battery warms up during charging. This is a
normal process.
Indications
The charger is equipped with red and green LED
indicators
that show the charging state:
■ Green LED illuminates:
3 Charger is ready to operate. The battery is fully
charged.
■ Red LED illuminated:
3 The charging process is activated. The battery is
being charged.
■ Red and green LED ash in turn:
3 Temperature fault; battery is too hot and cannot
be charged.
• Remove the battery and allow it to cool
down.
■ Red and green LED ash simultaneously:
3 Charging not possible; battery defective.
• Replace battery.
Battery charging state / maintenance
indication
The indication [4] on the device allows monitoring
of the battery charging state and indicates if mainte-
nance is needed.
■ It illuminates in red if the battery needs to be
charged.
■ It ashes in red if the device must be sent to
Würth masterService for maintenance.
