Working instructions (g. V)
Firing a pin
■ Hold the device rmly and stand in a stable
position.
■ Position the device rectangular to the material
surface. The sleeve [13] and the magazine foot
[9] must rest securely on the surface.
■ Press the device with the sleeve [13] against the
material surface.
3 This releases the safety of the device. The fan
motor is switched on and draws in air. Gas is
injected in the combustion chamber.
Caution
Never hold your hand directly in front of the intake
opening since this may cause malfunctions!
■ Press the actuator.
3 The gas mix is ignited electrically and the pin is
driven into the basis.
Note
Ignition is only initiated if the sleeve
[13] is completely pushed in and if at
least three pins are in the magazine.
■ Release the trigger and remove the device.
3 The exhaust gas is discharged via the openings
[14]. Simultaneously fresh air is blown in the
combustion chamber.
Note
If no further pin is driven in, the fan
continues blowing for approx. eight
seconds and is then switched o.
Warning
The device is designed for continuous
operation. In this process, the sleeve
can get very hot.
If you detect visible defects, immediately stop work-
ing with the device and have it repaired by Würth.
Driving depth adjustment
Danger
For safety reasons always remove the
battery and the gas cartridge from the
device prior to adjusting works!
Warning
The adjustment dial can get very hot
during operation.
The driving depth can be adjusted, if required, and
can be set by the adjustment dial [17].
■ Perform a test by driving a pin into the material.
■ Turn the adjustment dial [17] according to the
displayed mark.
Storage and transport
Danger
At the end of the working day, during
longer breaks, when transporting and
storing, always remove the battery and
the gas cartridges from the device.
Store the device and the battery in the genuine tool
box on a safe, dry, heat- and frost-proof place.
Always store gas cartridges separately and on a
save place. Unauthorized persons, in particular
children, may not get access to the device or to gas
cartridges.
Maintenance / care
To ensure trouble-free and safe working, the tool
must be regularly maintained. Use only Würth spare
parts for maintenance.
Danger
Never disassemble the tool with car-
tridges still inserted.
Wear safety goggles!
Due to the released pressurised air,
parts may be stirred up causing eye
injuries.
Cleaning the filter pad
Attention
Do never clean the housing opening
by means of pressurized air otherwise
dirt may get in the engine compartment
and damage the engine.
■ If exposed to great amounts of dust, the lter
pads must be cleaned after each working day.
■ Unscrew the cap with lter pad [1] and remove
for cleaning.
■ Clean lter pad using the pressurized air.
